36" Wide Commercial Grade 1 Push Bar Panic Exit Device in Dura Bronze R9500-DB-36
Specifications
Extracted Specification Data (Ready for Google Docs)
-
Source Document Reference: Bulldog CL8844 Heavy-Duty Surface Mounted Door Closer Technical Specification Sheet (Image Inputs)
1. Applications
-
Heavy-duty surface mounted door closer suitable for high traffic, high wind & heavy door applications.
-
Tri-packed for standard, parallel & top jamb installation.
-
Interior Door widths to 60 inches.
-
Exterior Door widths to 54 inches.
-
Door Weights to 330 lbs.
2. Certifications & Regulations
-
ANSI/BHMA Grade-1.
-
UL Listed - Compliant for positive pressure.
-
Conforms to UL10C & UBC7-2-1997.
-
Independently tested to 10 Million Cycles.
-
Badges: UL LISTED, Meets ADA Regulations.
3. Warranty
-
Lifetime Mechanical Warranty.
-
Two Year Finish Warranty.
4. Closer Functions & Features
Closer Functions
-
Size 1-6 (adjustable).
-
Barrier Free.
-
Adjustable closing & latching speeds.
-
Standard Back-check.
Closer Features
-
Cast iron body.
-
Forged steel arm.
-
Double heat treated steel pinion.
-
6 Stick-on mounting templates included.
-
Plastic Cover Standard.
-
Thru-bolts included.
-
Non-handed.
-
Aluminum (AL) and Duro-Bronze (DB) finishes.
5. Closer Arm Options
-
Cushion Stop Arm - PT-C88-CSA
-
Hold Open Cushion Stop Arm - PT-C88-CHO
6. Dimensional Specifications
|
Description |
Size |
|
A. Closer Length (with cover) |
12-1/4” |
|
B. Horizontal Mounting Holes |
See template / below |
|
C. Vertical Mounting Holes |
2-1/4” |
|
D. Overall Height |
4-7/8” |
|
E. Top of Door to Bottom |
3-11/16” |
|
F. Closer Height (cover) |
3-1/2” |
|
G. Projection from Door |
2-1/4” |
7. Bulldog Competitor Cross Reference Table
|
Bulldog |
Cal-Royal |
K2 |
LCN |
Norton |
Pamex |
Russwin |
Sargent |
Yale |
|
CL8844 |
CR441 |
— |
4041 |
7500 |
— |
2820K |
1230 |
4400 |
